HIGH SPEED CHECK WEIGHER CONVEYOR TYPE

INFORMATION

NWC3000 Series auto check weigher has been developed to satisfy the strictest production requirements, providing ease of operation, flexibility, hygiene, high-speed processing and optimum accuracy by measuring product weight quickly and precisely - rejecting "out of tolerance". Full color touch screen (10 inch TFT LCD) is easy to see and offers a simple user-friendly menus together with various conveneint functions. The unique modular design allows easy on-site adjustment for installation and remarkable accesibility for maintenance which enables minimal downtime.

MAIN FEATURES

Full Color TFT LCD Touch Screen (10 inch TFT LCD)

An intuitive and convenient full color touch screen, containing regional languages and user manual.

Digital Signal Processing Senosr (32 Byte Microprocessor)

Greater accuracy at high speeds can be obtained using 32 byte microprocessor which allows filter characteristics to be set automatically.

Dynamic Calibration

Dynamic calibration displays correct weight if there is discrepancy between the ready status and operational weight displays.

Auto/Manual Zero Adjust

Zero adjustment can be performed by the operator before start-up or product changeover. Also, Automatic Zero adjustment is programmed to occur at regular intervals during production.

Built-in Temperature Change and Noise Compensation Circuit.

3 Kinds of User Level Passwords

3 Kinds of User Levels (Operator, Quality Manager & Engineer Menu) can be set depending on possible operational functions.

3 Kinds of Operating Screens

3 Kinds of Operating Screens (Basic, Graph & Simple Screens) are provided depending on user taste.

No More Paper Manual Book

On-the go user manual on the screen guides the operator through necessary set-up and operational procedure on each stage.

Selectable Conveyor Belt Type

Either plastic chain belt or urethae belt can be selected for application.

Easy Product Record Statistic Function Internal Memory and USB Disk Backup / Recovery Display & IOB Board Firmware Update.

Optional Features External printer

An external printer can be installed to the control unit. Preset parameter data and various performance data can be recorded and printed.

Feedback Control (RS232C / 485 Ports & Dry Contact Signal)

Corrective control signals from the checkweigher to an upstream auger filler improve production efficiency.

Metal Detector

A high-efficiency metal detector can be easily added to provide an extra measure of safety and quality assurance.

Communiation Interfaces

Communication interfaces with a host computer or other external devices are available to help optimize your production line's performance.

Wash Down for Conveyor

Water Proof Motors and Stainless Steel Rollers are used for water proof.

Youtube Video: www.youtube.com/watch

*The final prices are determined by the dimensions of the machines after analyzing the needs of each case.

Outputs

Relay (5A) / 1A1B 2EA, DC24V SOL, AC220V 0.2A

Power Supply

Single Phase (110 to 220V) & Three Phase (220 to 380V and etc.,)

Free Cycle (50/60Hz)

Fuse (3A)

Operating Temperature

0℃ to 50℃ (advised to use the machine under normal temperature)
