METAL DETECTOR FOR ALUMINIUM-PACKED PRODUCTS

INFORMATION

NAD4000 Series metal detector detects even the smallest metal particles safely and reliably in every type of aluminum-packaged products.Compared with X-Ray scanners, NAD 4000 Series overcomes the high density differences in product or high evaluation thresholds due to variations in the production process. The intelligent, passive magnetic surface sensor works without wear, contrary to X-Ray scanners, and is easy to operate as the systems works without X-Rays. Wet and salty products such as cheese and meats do not affect detecting performance. Wires, chips and broken injection needles are reliably detected irrespective of product orientation.

FEATURES

Dual Sensor Type(More Stable Higher Accuracy).

Wider Conveyor Width Selection(250, 350 & 500mm).

Without Hazardous X-Rays - Wear - Free Detecting system.

No need to care about" product effect" & "Hot temperature".

Usable with every type of aluminum - packaged products.

Configurable passing height (Min. 50 ~ Max. 150mm by every 10.0mm) (For 250 & 350mm Conveyor width only).

Password Step Function.

Low investment and maintenance cost.

No need to be certified or inspected by government law.

Product orientation does not influence the signal strength.

Easy to learn & No need to train an operator.

Connectivity to Various External Devices.

Manageable Metal Detecting History.

Easy Software Update.

Youtube Video: youtu.be/sOvEdMR2FqU

*The final prices are determined by the dimensions of the machines after analyzing the needs of each case.

Outputs

AC Output: 4 ports / 24V Output: 4 ports Power Supply

Single Phase (110 to 220V) & Three Phase (220 to 380V and etc.,)

Free Cycle (50/60Hz)

Fuse (3A)

Operating Temperature

0℃ to 50℃ (advised to use the machine under normal temperature)

*Note : Metals that exhibit magnetic properties such as iron and SUS 430 and stainless steel processed by cutting and bending(placed under stress) such as SUS 304 and SUS 316 can be detected. Aluminum, brass, copper, silver, gold, lead, titanum, etc. cannot be detected because they can not be magnetized.
