CONVEYOR TYPE METAL DETECTOR

INFORMATION

NMD530 Series(SEEKER) Conveyor type metal detector is the most widely demanded model among NMD530 Series range products. Offering multi frequency operation system which is able to auto-select the correct operating frequency for maximum contaminant sensitivity in seconds. No longer are operators required to manually optimize frequencies, which is both time consuming and risky. Complemented by an array of innovative features and advantages, NMD530 Series (SEEKER) Conveyor type metal detector delivers tangible benefits to the manufactures at every key stage in their process and is equally effective in both “wet” and “dry” application.

Features

High Performance for Metal Detection

Closed Coil System for perfect detection.

High quality filter for more precise detection.

Auto absorption function for vibration, impact, noise and etc.

Dust Proof & Water Proof Standard (IP66) authentication.

Multi Frequency Operation

Supporting multi frequency operation mode that can measure various types of products with the correct operating frequency for maximum contaminant sensitivity in seconds.

Phase Tracking Function

Optimum detecting level is maintained by automatically coping with products of which phase is changed minutely, so detection is rather difficult such as frozen food.

Full Color Touch Screen (7 inch TFT LCD)

An intuitive and convenient full color touch screen, containing regional languages and user manual.

Digital Signal Processing Function

The adoption of 32-bit microprocessor has added more precise operation and performance of the equipment.Software filter technology to remove ambient noise affecting performance of a metal detector has been applied.

Exterior Design considering the convenience and aesthetics

Modern and sensuous design in which both convenience and beauty are emphasized at the same time.

Connectivity to External Devices

Backing up inspection history and etc., by using a USB removable disk and reviewing the data on a PC.

Monitoring real-time operating status for multiple metal detectors through the connective access to LAN.

Interlocking the machine to various typed external devices through RS232C & 485 port.

Auto-Setting Function of the Inspection Items

Auto-setting the machine for a testing product with the most suitable values even for beginners.

Setting Function of a Variety of Items for Convenient Operation

Up to 100 kinds of products are registered with each different setting value for convenient operation.

Manageable Metal Detecting History

Detection history by various classifications and periods (in a daily / weekly / monthly / period-specified way)

Data on detection history accessibility by LCD screen, USB disk and Printer (Optional).

Setting Function of a Variety of Items for Convenient Operation

Easy software upgradability by USB and touch screen whenever the latest version is available.

Password Setup Function

Setting up each three different passwords depending on each status (a user, an administer and an engineer).

YOUTUBE VIDEO: youtu.be/815vCviiGtg

*The final prices are determined by the dimensions of the machines after analyzing the needs of each case.

Outputs

Relay (5A) / 1A1B 2EA, DC24V SOL, AC220V 0.2A

Power Supply

Single Phase (110 to 220V) & Three Phase (220 to 380V and etc.,)

Free Cycle (50/60Hz) > Fuse (3A)

Network

Ethernet Port (TCP/IP Connectivity and remote monitoring support)

Serial Communication Port (RS-232C x 1 & RS485 x1)

Operating Temperature

0℃ to 50℃ (advised to use the machine under normal temperature)
